2GaB type twin screw pump
Overview
2GaB twin-screw pump can transport various viscosity, lubricating media, and allow the media to contain a small amount of impurities. The conveyed media include heavy oil, crude oil, fuel oil, mechanical oil, gear oil, hydraulic oil, turbine oil, water glycol, latex, etc., which are widely used in machinery, metallurgy, petroleum, chemical, electric power, shipbuilding and other industries. 2G series products can transport various viscosity and lubricating media, and allow the media to contain a small amount of impurities. The conveyed media include heavy oil, crude oil, fuel oil, mechanical oil, gear oil, hydraulic oil, turbine oil, water glycol, latex, etc., which are widely used in machinery, metallurgy, petroleum, chemical, electric power, shipbuilding and other industries.
Installation matters
1. Installation method: H means horizontal installation, F means bracket installation, L means vertical installation;
2. Specifications and models: the numbers in the first column indicate the specifications, and the numbers in the latter column indicate the specific lead. For details, please refer to the performance parameter table;
3. Seal form: N means built-in bearing and mechanical seal, W1 or no code means external bearing and mechanical seal, B means external bearing and metal bellows mechanical seal;
4. The relative position of the inlet and outlet: no code means right in and left out, Z means left in and right out, the direction of the relative position of the inlet and outlet is from the drive (motor) end to the pump direction;
5. Special requirements: No code means no special requirements, T1, T2, T3… means that the user has special requirements, and the specific model is provided by our company.
Capacity: 0.5~260m3/h
Outlet pressure: 0.2~1.6Mpa
Temperature of pumped liquid: ≤150°C, adoption exterior of add the water cooling structure, temperature of pumped liquid can reach to 300°C
Speed: 250~1450r/min
Viscosity range: 2~100000mm2/s
Application:For lubricating and non-lubricating liquids. Suitable for high viscosity or high temperature fields
