CY series gear oil pump
Overview
The circular arc gear pump is a kind of volume pump, which consists of two gears, pump body and front and rear cover. When the gear rotates, the volume of the space on the gear detachment side increases from small to large, forming a vacuum, which sucks the liquid into the gear meshing side. The volume of the space on the gear meshing side decreases from large to small, and the liquid is squeezed into the pipeline. The suction chamber and the discharge chamber are separated by the meshing lines of two gears.
Applications
1.Petrochemicals: Pure or filled bitumen, pitch, diesel oil, crude oil, lube oil etc.
2.Chemicals: Sodium silicate, acids, plastics, mixed chemicals, isocyanates etc.
3.Paint and ink.
4.Resins and adhesives.
5.Pulp and paper: acid, soap, lye, black liquor, kaolin, lime, latex, sludge etc.
6.Food: Chocolate, cacao butter, fillers, sugar, vegetable fats and oils, molasses, animal food etc.
Product Name | High viscosity pump |
Country Of Origin | china |
Structure | gear pump |
Power Supply | Electric |
Warranty | 1 year |
Support Custom | oem,odm |
Pressure | High Pressure |
Application | Commercial Buildings/Developing World Water Solutions/Industrial Boilers/Metal and Equipment Manufacturers/Biofuel Industry/Food and Beverage Industrywastewater treatment |
Type | Circulating Pumps/Fuel & Oil Transfer Pumps |
Outlet Size | Customized as required |
Model Number:CY;
Power Source:Electric;
Application:Sewage;
Customized support:OEM, ODM;
